Features
• Uncooled microbolometer infrared focal plane arrays, 640*512 pixel with 5X continuous zoom lens
• High sensitivity, NETD at 50mk, 25Hz
• 1080P HD camera with auto focus lens
• High performance video process chip and H.264 video coding, support HD resolution video image
• 360° pan rotating, can realize a full range monitoring and high accuracy position
• Sealed shell, smart shape, nitrogen inside, anti-harsh environment
• Low power consumption, stable performance
Specification
Monitoring Distance | HD Camera | Day: 6000-8000m | ||
Thermal camera | Object | Human(1.8m×0.5m) | Vehicle(2.3m×2.3m) | |
Detection | 5040m | 14400m | ||
Recognition | 1260m | 3600m | ||
Identification | 630m | 1800m | ||
HD Camera Lens | Focal length | 12.5~750mm | ||
Iris | F3.8~F22.C | |||
Auto iris | DC drive | |||
FOV | 28.8°~0.5° | |||
Fog penetrating | support | |||
Focus control | electronic | |||
Focus | Auto/manual | |||
Preset | Support lens zoom and focus preset | |||
HD Visible Camera | Sensor | 1/1.8''Progressive Scan CMOS | ||
Color mode | Integration ICR double filter switch between day and night | |||
Color mode | Integration ICR double filter switch between day and night | |||
Shutter speed | Auto/manual | |||
Fog penetrating | ON/OFF | |||
WDR | ON/OFF | |||
BLC | ON/OFF and area optional | |||
Noise reduction | 3D digital | |||
Code type | H.264/MJPEG/MPEG4 | |||
Resolution | 1080p, | |||
Video rate | 32Kbps~16Mbps | |||
Frequency | 50Hz:25fps(1920×1080),25fps (1280×720) 60Hz:30fps(1920×1080),30fps (1280×720) | |||
Character adding | Camera number, time, date | |||
Image adjustment | Light, contrast, saturation, sharp | |||
Thermal Camera | Detector Type | Uncooled FPA, 640*512 pixel | ||
Spectrum Range | 8~14μm | |||
Lens | 36~180mm | |||
FOV | 3.5°×2.6°~17.2°×12.9° | |||
IFOV | 0.09~0.47mrad | |||
NETD | 50mK@F1.0, 300K | |||
Frame | 25Hz | |||
Electric Magnification | 4x | |||
Lens Control | Electric zoom and focus | |||
Image Process | Digital detail enhancement (DDE),palette | |||
Video Output | NTSC/PAL | |||
Pan-tilt | Rotating Speed | Pan 0~ 30°/s;Tilt 0°~15°/s | ||
Rotating Angle | Pan: 360° ,Tilt: -45~+20° | |||
Presetting Bits | 128 | |||
Positioning accuracy | ±0.1° | |||
Repetition Accuracy | ±0.1° | |||
Lens presetting bits | support | |||
Auto Cruise | support | |||
Protocol | Pelco-D、Pelco-P | |||
Baud Rate | 2400/4800/9600/19200 bps optional | |||
Operation Temperature | -25℃~+55℃ | |||
Storage Temperature | -40℃~+65℃ | |||
Bearer Mode | Up load | |||
Drive Mode | Worm Gear | |||
Interface | Power | DC30V | ||
Internet | 1×10Base-T/100Base-TX,RJ45 | |||
Shield | Material | High precision aluminum alloy shell | ||
Structure | Integration double window | |||
Windows Glass | 4mm microcrystal optical window | |||
Surface Coating | PTA Tri-proof Coating, Anti-salt water | |||
Protection Grade | IP66 | |||
Interface | Waterproof aviation plug | |||
Environment Indicator | Operation Temperature | -25℃~+55℃ | ||
Storage Temperature | -40℃~+65℃ | |||
Anti-vibration | 15m/s2 5~200Hz | |||
Anti-impact | 150m/s2 11ms | |||
Salt Fog Proof | Continuously spraying 48 hours under PH 6.5~7.2 |
